Electrical Insulation Laminates

Learn more about our super clean polypropylene paper laminates.

Electrical Insulation Laminates

Next to our base papers for laminates we also offer polypropylene (PP) paper laminates. Our electrical insulation laminates offer a super clean electrical grade resin. Consisting of two layers of paper and one layer of PP bonded together.

Benefits

  • Very low oil swelling
  • Low dielectric losses
  • High electric strength

Features

  • Available in 94, 119, 125, 168 µm
  • Roll core dimension 75 ± 1 mm
  • Roll dimension 600 mm
  • Roll width 750 mm ± 4 mm

Application

  • HV mass impregnated cables
  • High temperature superconducting cables
  • EHV pipe type cables
  • Other dielectric purposes
